CrN / CrCN
CrN / CrCN — chrome nitride / chrome carbon-nitride For a high level of adhesion
CrN exhibits good sliding properties with minimal lubrication. The high hardness and very low brittleness allow thicker CrN coatings with very good adhesion to the substrate.
The chrome-nitride coating is characterized by the following properties:
- High hardness and adhesion.
- Very good chemical resistance.
- High-temperature resistance in air
- Thicker layers possible
- Low coefficient of friction against steel
In Numbers
Hardness: (CrN) 2,000 ± 200 (CrCN) HV 2,300 ± 200 HV
Max. application temperature: 600 °C / 1,110 °F
Coefficient of friction against steel: (CrN) 0.3 – 0.4 (CrCN) 0.2 – 0.3
Coating thicknesses: (CrN) 1 – 6 µm (CrCN) 2 – 6 µm
Color: (CrN) slate grey (CrCN) silver grey
- Aluminum die casting: (Duplex► coating of cores and form-giving active segments for the reduction of wear.
- Machining: Milling, turning, grinding and cutting-tools for the processing of non-ferrous metals, particularly Ti and Cu alloys.
- Plastic molding: Tools which are subject to corrosive and abrasive wear, e.g. through aggressive and hard filling materials.
- Shaping: Drawing, stamping, pressing and deformation tools for the processing of non-ferrous metals, especially Ti and Cu alloys.
